Voss Modern Bath Shower Mixer Tap

This designer contemporary style Voss bath shower mixer combines a round body with an angular waterfall spout. Waterfall design taps providing a touch of sophistication to any bathroom. Manufactured from solid brass with a brilliant chrome finish and complimented by lever action handles that gives finger too control of the temperature and water flow. A stylish diverter allows for switching between bath fill and showering action.

Technical Specification

• Height :132mm
• Total Projection : 123mm
• Width : 222mm
• Tap Inlet Centres : 180mm
• 3/4 water inlet feeds
• Working pressure between 0.5 and 5.0 bar pressure
• High quality design and build
• Latest 1/4 turn ceramic disc technology
• Material : brass body
• Highly polished chrome finish
• Hot and cold indicators (H & C) on lever controls
• Comes complete with shower handset, hose and wall bracket
• Deck mounted
• Easy installation
• Gravity systems require minimum of 5 metre drop between bottom of water tank and bath filler tap (suggest using a shower pump on gravity fed systems)
• Suitable for combi boilers and pressurised systems between 0.5 and 5.0 bar pressure
• Suitable for shower pumps
• Complete with installation instructions
• Guarantee : 5 Years
• Flow Rates :-
• 0.5 Bar   15.0 Litres per minute
• 1.0 Bar   22.4 Litres per minute
• 2.0 Bar   31.8 Litres per minute
• 3.0 Bar   33.5 Litres per minute

NB:  All measurements are approximate. In line with manufacturing policy we reserve the right to amend specification without prior notice .
